Nova Plus 24
Nova Plus 24
Looking to size up? Look no further. Our Nova Plus series of machine is the upgraded version of our flagship series and they pack a ton of bang for the buck.
Starting as low as $154.41/mo. Learn More
Couldn't load pickup availability
Speak to an ExpertFast & Secure
-
-
-
-
-
-
-
-
View full details
- Description
- Material Capabilities
- Technical Specs
Looking to size up? Look no further. Our Nova Plus series of machine is the upgraded version of our flagship series and they pack a ton of bang for the buck. All RF, more work area, and all the bells and whistles you could ever want. True industrial-grade at these price points is unbelievable. Too good to be true? Not here.
We have two models of Nova and they’re named by how wide the work area is. We have a 24″ wide and a 35″ wide.
With the Nova Plus, all you have to decide is which size to get!
The #1 Production Laser
Speed and Precision
- High-speed hybrid servo motors, up to 1,200mm/s
- Up to 4x faster than hobby lasers
- Higher wattage for cutting thick materials
- Up to 2,000 DPI with 1.5" head
Extra Features
- Dual-stage air assist: Different air flows for engraving vs cutting
- Auto-focus, Red Dot Pointer, and Status Indicator Light
- Built in crumb tray to catch the scraps
- Smart board turns air and exhaust on/off with each job
Durability
- Durable gantry ensures high-quality engravings
- Industrial-grade chiller included
- Heat Alarm + other safety features
All-enclosed Design
- Up to 35" wide work area
- Motorized Z-Table fits up to 9" tall parts
- Great for production runs
| Material | Engrave | Cut |
|---|---|---|
| Wood |  |
|
| Acrylic | |
|
| Fabric | |
|
| Glass | |
x |
| Coated Metals | |
x |
| Ceramic | |
x |
| Delrin | |
|
| Cloth | |
|
| Leather | |
|
| Marble | |
x |
| Matte Board | |
|
| Melamine | |
|
| Mother of Pearl | |
|
| Paper | |
|
| Mylar | |
|
| Pressboard | |
|
| Rubber | |
|
| Wood Veneer | |
|
| Fiberglass | |
|
| Painted Metals | |
x |
| Tile | |
x |
| Plastic | |
|
| Cork | |
|
| Corian | |
|
| Anodized Aluminum | |
|
| Stainless Steel | * | |
| Brass | * | |
| Titanium | * | |
| Bare Metals | * |
*CO2 lasers will mark bare metals when coated with a metal marking solution.
| Engraving / Working Area | 23.6″ x 15.7″ x 6.1″ (desktop model – a stand is recommended) |
| Max Part Size | Pass through closed: 24.2″ x 18.5″ x 6.1″; Pass through open: 24″ x ∞” x .8″ |
| Laser Wattage | 60w RF |
| Intelligent Memory Capacity | Multiple File Storage up to 1GB |
| Laser Source | RF Metal CO2 Tube, stringently tested to pass Quality Control. Average lifespan: up to 10,000 working hours. |
| Electrical Requirements | Standard 110v AC 60Hz Single Phase, dedicated 15A circuit |
| Air Assist | Air pump 5-7psi included |
| Machine Size | 44.1″ x 34.9″ x 26.9″ |
| Software | LightBurn Software included for two computers. Compatible with Windows, Mac, and Linux. |
| Training | One hour remote setup training included, optional four-hour training available |
| Red Dot Pointer | Shows where laser will fire, allows for “dry run”, and easy positioning on material |
| Camera System | Comes with an over-head camera as standard |
| Operating Modes | Optimized raster, vector, or combined modes |
| Easy Adjustable Home | When engraving items that are not easily placed at the top corner of the laser, you can set a new home position by hand with a new origin |
| Motion Control System | LeadShine Hybrid-Servo Motors with engraving speeds up to 1,200mm/s (39″/second) |
| Resolution | Up to 500dpi with included 2.5″ head or 2,000dpi with 1.5" head |
| Safety | Open cover protection, no-water protection, heat alarm system |
| Auto Focus | Infrared Auto-Focus system to easily bring material into focus |
| Belts | High-quality fiberglass reinforced neoprene belts |
| Water Chiller | Not needed as this is an air cooled machine |
| Ventilation | 375CFM Exhaust Fan, 6″ port on rear of machine |
| Motorized Table | Includes removable honeycomb and solid metal blade (knife-style) bed |
| Laser Heads | 2.5″ Head / Lens included, optional 1.5", 2", and 4" Heads |
| TL-Timer (Smart Board) | Relay switch that controls exhaust and air assist when the laser is idle |
| Warning Light | Visible red/green light indicates job completion |
| Support | Free USA-based lifetime support with fast response times |
